Belt Chocolate/Powder Coating and Polishing Machine

Short Description:

Chocolate Coating machine and Chocolate Polishing machine are mainly used in stuffed products with peanuts,almonds, raisin,puffed rice balls,Jelly candies, hard candies ,QQ candies etc.

Item No: lstcoater-300

Capacity: 200-400kg/h 330L/batch

Dimensions: /

Certification: CE

Customization: for 1 set

EXW Price: /

Send email to us Download as PDF

Product Detail

Product Tags

●Features

1.Automatic production, save manpower / high production efficiency / large output.
2.Full automatic chocolate feeding,coating and shaping.
3.Auto weighting and auto switching for hot air and cold air.
4.Programmed production process makes product
5.Chocolate atomized spray and pouring meets special requirements of different product.

●Application

-Can auto coat chocolate

-Can auto coat powder

1.or fragile products and puffed product, Diameter ≥4mm, stuffed material ≤250 liters. The more fragile, the less material.

2.For products with corner and edges,round shape and consistent thickness is not suggested.

3.For adhesive product, put less adhesive material. In case materials stick together and effect the shaping.
4.For chocolate paste, it is necessary to filter before add in to avoid block of spray nozzle.

●Parameter

Belt chocolate Coating Machine	Output	200-400kg/h 330L/batch
	Total Power	15KW
	Dimension	2450-1650-2250mm
	Net Weight	800kg
	Belt Speed	5-20m/min
	Belt Width	1650mm or customized
	Compressed Air	0.4MPa
	Power Supply	380V 50HZ or customized
Belt chocolate Polishing Machine	Output	200-400kg/h 330L/batch
	Total Power	12KW
	Dimension	2450-1650-2250mm
	Net Weight	800kg
	Belt Speed	5-20m/min
	Belt Width	1650mm
	Compressed Air	0.4MPa
	Power Supply	380V 50HZ or customized

●Samples

●Flexible Layout

●Operation Process

1. Chocolate Belt Coating Machine
-Chocolate belt coating &molding machine
-Chocolate material feeding system
-7P industrial refrigeration units(water cooling and air cooling system)

2.Dry Storage(by buyer)
-A separate room which need to be more than 15㎡,low temperature and humidity. Chocolate will place in room about
-8-10 hours to dehumidify and solidify. It will increase the glossiness and shelf time of chocolate. Customers are advised
-to put product in small pallet and put on multilayer shelves.

3.Chocolate Polishing Machine
-Chocolate Belt Polishing Machine

-7P Industrial refrigeration system

4.For Special Product
-Or fragile products and puffed product, Diameter ≥4mm, stuffed material ≤250 liters. The more fragile, the less material.
-For products with corner and edges,round shape and consistent thickness is not suggested.
-For adhesive product, put less adhesive material. In case materials stick together and effect the shaping.
-For chocolate paste, it is necessary to filter before add in to avoid block of spray nozzle.
